Product revision! Larger ports, and added baffle! Same great price!
What does the Damond Motorsports PCV Plate do, and what does it offer?
The PCV plate is a fully machined replacement of the factory PCV oil separator plate, with a port machined to accept an OEM Mazda PCV valve and o-ring, as well as two additional large -10 ports, thus allowing you to run a variety of PCV and OCC set-ups. With this latest version we have added a baffle plate to help reduce the amount of blow-by out of the PCV plate.Ā
Incorporating a PCV valve port onto our plate means you are able to maintain the correct amount of vacuum on the crankcase, under all engine vacuum conditions. With the additional ports, youāre now able to easily and cleanly run dual OCC set-ups in whatever configuration that suits your car best to relieve excess crankcase pressure.Ā The PCV valve is held into the the DM PCV plate with a retaining ring, allowing for easier install and removal of the valve.Ā
To purchase hose fittings please visit:Ā hereĀ
For more info on different dual OCC set-ups, please visit our blog page here
Ā
Each Damond Motorsports PCV plate comes with the following:Ā
Optional extras that can be purchased along with the PCV plate:Ā
Ā
This was supposed easy to put in and I came on time I love working with this company and hope on day I could get a sponsorship I told all my friends about it and I also love the packaging
I the PCV was better quality than I had expected. I did have 2 problems to over come upon installation. One is don't over torque the bolts. (Personal installation error) 2nd for my 2011 Mazda Speed 3, I was unable to make the OEM PCV hose work for my car. Due to the angle of the oem pcv hose having an extra bend in it it was damn near impossible to install. So I went to the parts store and got a collant hose and cut it to lenth. Other than that, I would 100% reccomend this product. Great job Damond Motors!
Great build quality and design. Just a bit tricky to install by needing to take the intake manifold off.
Could not be happier with this product, we have supplied these plates to over 10 speeds in South Africa. Great quality product and even better customer service from Damond Motorsport team. Keep it up šš¼šš¼šš¼
Fast shipping and great quality parts
Made with quality materials, exact fitment, works and looks fenomenal.
Good quality, perfect fit, and with the oil catch can, perfect combination.
This is a great thick boy piece of aluminum that does its job amazingly. If you are even installing just a Stage 1 OCC (like I was) it helps out a lot with pointing the stock PCV in a way better direction to run your hoses over to the OCC. I have NEVER disliked any Damond Motorsports products and this one is also GREAT.
Done as part of my valve cleaning, egr delete, and sending off the injectors. This is one of the best engineered pieces I have seen for a car. The piĆØce de rĆ©sistance was 10mm bolts to replace the factory 8mm, its attention to details like that that makes DM products so great.
Great product, perfect fit, second catch can isnāt posted in the picture, but either way itās a solid product, better than oem, definitely recommend
Excelent quality and service
This is a great well made part, seems to be even better than the older model plate that it replaced. Damond supplies all the parts needed. A affordable investment for piece of mind. Just get the gold!
I left a negative review a couple of days ago, which hasn't been posted yet. Turns out it was my ignorance. The kit comes with a stock PCV o-ring and a retaining ring. (I don't actually know if the retaining ring is a stock part or not.) But, I didn't notice those parts in the bag. And I didn't originally notice the parts list on the page. So, I didn't know those parts existed. So, I couldn't understand what was supposed to hold the PCV valve in place. Or, in my case, since I'm using the plug, I couldn't figure out what held the PCV plug in place.
I went looking on this site for a guide and didn't find one. The catch-can kits have instructions that mention the plate and have a sketch of it. But no actual pictures or directions. Thus I had difficulty figuring out where I was going wrong.
So today, I decided to look again at this site just in case there was something I was missing. And eureka, I see the clip in the picture of the product, then see it in the list of parts that come with the kit. I was afraid maybe I inadvertently threw them out since I didn't know they existed, but I found them in the bag with the screws. Eureka!
But when I first see the clip and the plug that it is supposed to hold, I'm just not convinced that it is going to hold it well. I'm afraid the retaining ring might pop out if you push on the plug a little. Well, no, it doesn't. The ring holds it quite well actually!
And ultimately, my difficulty might be the proverbial blessing in disguise. You see, I was originally planning on using a stock PCV valve in my set-up. When I became convinced that the retention system for the stock valve didn't work (even though it did...) I decided to heck with it, I'll get the plug and use higher quality, higher flow check-valves. Now that I know the retention system does in fact work, I could go either way. But I'm now convinced that the higher quality higher flow check valves are what I want.
See picture with plug and ring
Got this plate for my 2011 Mazda 3 2.5l and couldnāt be happier with product expect the fact Iām now changing intake manifolds due to none of the hose and fittings coming out of plate fit with the manifold bolted down. Broke the stock valve trying to make it fit and still couldnāt get enough room for the smallest fitting included. Would have been nice if it said some madifying required at least haha. Great product though and looks so good mocked up
Packaged well and quality is great. Will be ordering from Damond motorsports again!
Looks so good and it was very easy to install
Shipped quickly great product overall definitely recommend
Works fantastic on my Gen 1, solved pretty much all my blow by issues, now my dipstick doesnt try to launch itself into the stratosphere!
Great quality, plate is like a piece of art. Too bad mostly hidden under the manifold. Install made easier as had the intake manifold off so easy access. Installing new PCV valve at the same time, was having issues getting it to sit right with the C clip. Made a call, recommended putting "O" in the plate first, not on the Valve, and apply some oil, went in super easy. Might just include a note on that with the parts.
huge improvement over stock, and looks great too!
Amazing craftsman ship and a huge improvement over stock! Should be on the list of must do upgrades!
Ordered so many parts through Damond and they always come quick and are always great quality. Best part store for the speed3 platform
